D5(Zebra) / Premium All-terrain Electric Fat Bike
-
Shipping:Within 2 Business Days
-
Torque
Sensor
-
960 Wh
Samsung/LG Battery
-
80 Miles
Max Range The range can be affected by several factors like rider weight, incline, and pedal-assist levels, etc.
-
750W
Motor
-
20+ Mph
Top Speed Reach speeds of up to 20 mph, No pedaling required.
-
400 lb.
Max Playload
- 1 - The range can be affected by several factors like rider weight, incline, and pedal-assist levels, etc.
- 2 - Reach speeds of up to 20 mph, No pedaling required.
Why The Himiway Zebra Is A Very "Solid" E-bike!!
Monkey Wrench Mike
Riding My HIMIWAY D5 ZEBRA With My Wiener Dog, Gus! Jennifer Sugint- NNKH
Jennifer Sugint
This Is A First In This Household // Himiway Zebra E-Bike
Trucking With Schmidt
HIMIWAY D5 ZEBRA
Kens Karpentry
960Wh Samsung/LG Lithium-ion Battery
It combines the new Samsung/LG battery technology with a 5000mAh single cell capacity in a smaller size but with larger diversity. Compared with 3500mAh cells made of nickel, cobalt, and manganese, this 960Wh battery efficiently improves the range, stability, and safety of Himiway bikes. A single charge can last up to 60 miles on pure electric power and 80+ miles with pedal assist. The battery will maintain 80% capacity after 1000 charges.
-
Removable
Built-in Battery -
60-80 Miles
Pre Charge
400 lb. Payload With 2X Thicker Frame
It boasts an upgraded 6061 Aluminum frame that is 2 times thicker than conventional bike frames, with an integrated battery design. This robust frame can support weights of up to 400lbs, while maintaining the stability of the motor and battery. Riding the D5 feels like being on a tank when going off-road, providing a solid, safe, and reliable riding experience.
-
Aerospace Grade
Aluminum Frame
Fast Acceleration & Good Gradeability & Longer Lifespan
750W Upgraded Brushless Geared Hub Motor Use the latest updated inner ring specialized in high temperature resistance and better heat dissipation, which can reduce the motor magnets’ attenuation speed to guarantee a longer life expectancy. The 750W brushless gear hub motor can help you conquer even the most rugged terrain easily.
-
750W
Motor Power -
86Nm
Max Motor Torque
The advantages of a Torque Sensor
Torque sensors offer efficient power delivery, extending battery life for more miles.This can feel much more natural than a bike with a cadence sensor, as it replicates the feeling of riding that many of us are used to and simply amplifies your efforts. Pedal hard and you’ll get maximum assist.
Features
Hydraulic Brakes
Hydraulic brakes provide superior braking performance and durability. With proper maintenance, there won't be a decline in braking power for 5 years.
48V 500LM Luminosity Spotlight
The Himiway independent R&D luminosity spotlight is 20% brighter than LED light. Visibility is improved to guarantee your safety while riding at night.
Customized Integrated Brake Light
The automatic brake light with Himiway logo will be activated whenever you use the brake, which can prevent rear-end collisions while riding at night.
Thumb Throttle
The thumb throttle are designed for professional cycling enthusiast. Your both hands are more capable of keeping the balance of Himiway Rhino/Rhino pro.
Kenda All-terrain Fat Tire
26"x4" Kenda K-shield fat tires provide strong grip and traction on rugged roads. Even on the most challenging terrains and weather conditions, these fat tires can guarantee your safety and offer you an easy and smooth riding experience.
Easy to Assemble
Unboxing VideoTechnical Specifications
Geometry
-
A – total length78.7
-
B – handlebar height47
-
C – handlebar length28
-
D – wheelbase49.2
-
E – wheel diameter28.7
-
F – minimum seat height20.9
-
G – maximum seat height31.4
-
H – chain stay length19
-
I – frame stack24.6
-
J – frame reach17.8
-
K – effective top tube length24.4
-
L – head tube length5.5
-
M – head angle65°
-
N – standover heightST 22.4/ SO 31.1
Specification
-
Frame6061 Aluminum frame
-
HeadsetNeco H156EM 28.6*44-56*30
-
ForkTRAMA 26""FAT34-26-HLO 95mm travel 9*135mm quick release
-
Front wheelRim: MD-147 26*4.0"*36H*12G A/V | Spoke: 12G 255/256L stainless (304M) | Hub: MB015-92 M9*12G*135*145W
-
Rear wheelRim: MD-147 26*4.0""*36H*12G A/V Spoke: 12G 214L stainless (304M) Hub: 48v 750w Himiway hub motor
-
TiresKenda 26*4.0
-
BatterySamsung/LG 48V 20Ah
-
Motor750W brushless gear motor
-
DisplayLCD display with USB charger
-
ThrottleThumb throttle
-
SensorsTorque sensor丨speed sensor丨brake sensor
-
CranksetCrankarm: Prowheel EB-01-242A-S1 170mm | Chain ring: 44T BCD104
-
FreewheelShimano MF-TZ500-7 14-28T
-
ChainKMC Z8.3 EPT 120L
-
GroupsetShimano altus M310 7 speed
-
Front brakeTektro HD-E3520 hydraulic brake
-
Rear brakeTektro HD-E3520 hydraulic brake
-
RotorsTektro TR180-52 F:180mm R:180mm
Components
-
StemZoom TDS-C269-8FOV 31.8*90mm
-
HandlebarPromax HB-3188 22.2*31.8*700mm
-
SeatpostHimiway Seatpost
-
SaddleHimiway Saddle
-
PedalAluminum pedal
-
Lights48V LED light
-
KickstandHeavy-duty aluminum kickstand
Others
-
Range60-80 miles
-
Controller48V/22A
-
ChargerUS standard 3.0 A smart charger
-
Rider height5′3″ ~ 6′5″
-
Weight79 lb. (with battery)
-
Max. payload capacity400 lb.
*Himiway has the right without notice to the consumer to substitute components of at least equal quality for advertised Himiway ebike components in the event of the unavailability of such advertised components.
Recommended for you
D7 / Full Suspension Electr...
D7 Pro / Softail Electric M...
Customer Reviews
Easy set up. Great bikes!
I love the color of my new bike (a moss green) and most things about it. However, I had purchased a previous Hemiway e-bike Cruiser and the accelerator was great, on the right side of the handlebars and worked well. On the new Zebra bike they located the accelerator on the left side and it is now a lever. A little hard to control when taking off from a stop light, etc. Other than that, I love my bike!
I researched a lot of brands and too time to find the best choice for our family. Mandy was extremely patient and answered all of my questions. She really made the difference in my descion process. Our D7 and D5 arrived damage free and easy to assemble. I will only recommend to others for its value, quality and support.
Last night, I decided to drain the battery,
I first rode behind the Twence waste processor and (secretly) took the footpaths, as there are no pedestrians in the evening, but I did see a beautiful piece of nature (captured in video and photos). I just wanted to experience the battery's endurance for myself. The specifications indicated 125 km, while some mentioned 130 km. I wanted to find out. I rode the last 5 km around my house and yes... at 129.8 km, the assistance cut out. I could still turn on the lights, though. Now I know that when the last bar starts blinking, I still have about 15 to 20 km of support left — the 'reserve tank' in motorbike terms. That's what I wanted to understand.
I know that initially, you need to drain the battery at least 5 times until the assistance stops, after which you can do it at your discretion when it blinks. It's battery training for a longer 'lifespan' of the battery. I had already done this with the Flyer T7 (which I still have), and the Flyer dealer was surprised at how long I used a single battery.
I usually bike around 22 km/h in the 3rd assistance level. I only switch to the 5th assistance level for viaducts or small hills.
How was it to pedal without assistance? It wasn't too bad; the Shimano gears are excellent for control, but it felt like having a brake parachute 🙈😅 After all, the bike weighs 35 kg.
I love this bike. It's amazingly easy to ride.
I purchased a D5 Zebra Pro in the beginning of February 2025. I’ve called numerous times left messages & got no response. I’m disabled so it’s hard to find help to use chat. The box says just D5 not D5 Zebra. I just got someone to help me assemble it today. I don’t want to open the box in case I received the wrong bike. Can someone please help me. I’ve left messages since February! I’d appreciate your help & time. Thanks Marcus
Hi Marcus,
Thanks for reaching out to Himiway!
Upon checking your order (order ID: Himiway75324123), you purchased a D5 Zebra, not D5 Pro. And the box says D5 is correct. Because D5 means D5 Zebra. You can open the box and enjoy the ride.
Should you have any other concerns, please feel free to reach out. Wish you a nice day.
Just hit 100 miles. Love the bike. Rides great and is pretty true to miles per charge. My only gripe is with CS. Ordered a phone holder and water bottle holder. Took over a month and half before it arrived, and both sucked! Ended up buying on amazon for literally half the cost and better quality. Other than that, bike is great so far.
We ordered a total of 4 bikes and accessories. Two of the bikes arrived quickly within a week of ordering. The other 2 bikes got held up due to tarrif shipment issues. Customer service specifically “Leo” worked with me to redirect shipment of one of the bikes due to the extended shipping time. All of our bikes arrived in good condition. So far we have had a positive experience with the Himiway customer service crew. We look forward to using them as a family. We are riders from 19 yrs old to 65. The bikes are great so far. Our daughter bought the child / dog carrier and her old border collie is loving the rides…❤️
I recently purchased a Himiway bike and I’m extremely satisfied with the experience. The bike performs great, it’s sturdy, and very comfortable to ride. What impressed me the most was the customer support — always helpful, quick to respond, and truly committed to solving any issues. The technical assistance is also reliable, showing that the brand really cares about its customers even after the purchase. I highly recommend Himiway!
