Bafang has officially announced the production versions of its highly anticipated high-performance racing e-MTB drive systems: the M510RS and M560RS. First shown as concepts, these new mid-drive motors feature integrated 6-axis Inertial Measurement Units (IMUs), optimized control algorithms, and a new Boost-to-Limit function that delivers up to 800% pedal assistance and 1,700W of peak power.
The production systems are making their public debut at the International Bike Festival (IBF) in Italy.
New Bafang RS Mid-Drive Lineup
| Specification | Bafang M510RS | Bafang M560RS |
|---|---|---|
| Best For | Performance trail e-MTB & technical climbing | Extreme e-MTB & steep, loose terrain |
| Torque | 110 Nm (up to 130 Nm with Boost) | 120 Nm (up to 150 Nm with Boost) |
| Peak Power | 1,100W (36V) / 1,300W (48V) | 1,400W (36V) / 1,700W (48V) |
| Mounting | Standard M510 mounting | Standard M560 mounting |
| Speed Versions | EU: 25 km/h / US: 28 mph (45 km/h) | EU: 25 km/h / US: 28 mph (45 km/h) |
Key Technology Upgrades
Intelligent Power Delivery
Built-in 6-axis IMUs continuously monitor the bicycle's pitch and terrain. This allows the updated Sport+ mode to adapt assistance fluidly, making power delivery feel more intuitive.
Rapid System Responsiveness
The RS line responds 50% faster than the standard M510 and M560 motors and delivers a 33% more sensitive power cut-off for improved rider safety and traction control.
Boost-to-Limit Support
Cyclists can temporarily unlock up to 800% assistance on demand, providing additional power for particularly steep climbs and challenging terrain.
Enhanced Trail Features
The new systems include integrated Hill Hold, which helps prevent the bike from rolling backward during steep starts, along with an upgraded Walk Assist 2.0.
Drop-In Manufacturing
Frame builders do not need to redesign existing bicycle frames because the RS variants use the same mounting footprints as the previous M510 and M560 generations.
Bafang M510RS
The Bafang M510RS is a high-performance mid-drive motor designed for 27.5-inch and 29-inch electric bikes. It combines a rated power of 250W with significantly higher peak output, torque sensing, and an adaptive Sport+ riding mode.
Core Specifications
| Specification | Bafang M510RS |
|---|---|
| Motor Position | Mid Motor |
| Wheel Diameter | 27.5–29 inches |
| Nominal Voltage | 36V / 48V |
| Rated Power | 250W |
| Max. Possible Power | 1,100W / 1,300W |
| Max. Possible Torque | 120 Nm / 130 Nm |
| Max. Support Ratio | 800% |
| Speed Limit | 25 km/h |
| Pedal Sensor | Cadence & Torque |
| Shaft Standard | BAFANG |
| Color | Black |
| Weight | 2.9 kg |
Functions
Auto-Adaptive Mode (Sport+)
The M510RS supports Sport+, Bafang's auto-adaptive riding mode designed to dynamically manage motor assistance.
Auto-Hold Mode
Optional. Auto-hold can help prevent the bike from rolling backward when stopped on an incline.
E-Brake
Optional. The motor supports an electronic brake function depending on the bike configuration.
Throttle
Not available.
Coaster Brake
Not supported.
Additional Features
| Feature | Specification |
| Light Drive Capacity | 12V / 12W max |
| Chain Guide | ISCG05 |
| Water Resistance | IPX6 |
| Certification | CE |
Bafang M510RS at a Glance
The M510RS combines a 250W rated output, up to 1,300W maximum possible power, up to 130 Nm of torque, and a maximum 800% support ratio in a relatively lightweight 2.9 kg mid-drive system.
Its combination of cadence and torque sensing, Sport+ auto-adaptive assistance, IPX6 protection, and compatibility with 27.5-inch and 29-inch wheels makes it particularly suited to performance-oriented electric mountain bikes.
Bafang M560RS
The Bafang M560RS is a high-performance mid-drive motor designed for 27.5-inch and 29-inch electric bikes. It combines a 250W rated power with high peak output, strong torque, cadence and torque sensing, and Bafang's adaptive Sport+ mode.
Core Specifications
| Specification | Bafang M560RS |
|---|---|
| Motor Position | Mid Motor |
| Wheel Diameter | 27.5–29 inches |
| Nominal Voltage | 36V / 48V |
| Rated Power | 250W |
| Max. Possible Power | 1,400W / 1,700W |
| Max. Possible Torque | 140 Nm / 150 Nm |
| Max. Support Ratio | 800% |
| Speed Limit | 25 / 45 km/h |
| Pedal Sensor | Cadence & Torque |
| Shaft Standard | BAFANG |
| Color | Black |
| Weight | 3.3 kg |
Functions
Auto-Adaptive Mode (Sport+)
The M560RS supports Sport+, Bafang's auto-adaptive riding mode.
Auto-Hold Mode
Optional.
E-Brake
Optional.
Throttle
Optional.
Coaster Brake
Not supported.
Additional Features
| Feature | Specification |
| Light Drive Capacity | 12V / 12W max |
| Chain Guide | ISCG05 |
| Water Resistance | IPX6 |
| Certifications | CE / UL2849 |
Bafang M560RS at a Glance
The M560RS combines a 250W rated output, up to 1,700W maximum possible power, up to 150 Nm of torque, and a maximum 800% support ratio in a 3.3 kg mid-drive system.
It also features cadence and torque sensing, Sport+ auto-adaptive assistance, IPX6 protection, optional throttle support, and compatibility with 27.5-inch and 29-inch wheels.
Other Notable Recent Releases
Bafang H730 Hub Motor
For urban riders, Bafang has introduced the H730, an automatic-shifting rear hub motor in its GVT line. The system automatically manages shifting without requiring external mechanical shifting cables.
M615 CAN-Bus BBSHD Kits
For DIY e-bike conversions and retrofits, Varstrom and other suppliers are distributing updated 2025/2026 Bafang BBSHD 1000W kits featuring modern CAN-Bus controllers and squared-head safety connections instead of the older UART connections.
